Motion Controlled Robotics
The Motorized Precision EVO is a compact, highly portable 6-axis cinema robot designed for precise, repeatable camera movement in both studio and location environments. Weighing just 44 lbs with an 11 lb payload capacity, it brings professional motion-control capabilities to a wide range of productions without the bulk of larger systems.
The EVO excels at complex multi-axis moves that are difficult to achieve consistently by hand or with traditional jibs and dollies. Ideal for product and tabletop cinematography, it delivers smooth orbital shots, precise push-ins, rising reveals, and dynamic paths around small subjects. Its small footprint and quick setup make it especially useful for commercials, music videos, branded content, and other productions where repeatable moves are essential.
EVO Specs
BASE
Mitchell Mount
REACH
Maximum Height (Z- Axis Max) — 4 ft /1.20 m
Lowest Position (Z-Axis Min Relative To Base) — -1.30 ft / -0.40 m
Maximum Reach (From Center) — 2.79 ft / 0.85 m
PERFORMANCE & PRECISION
Maximum Joint Speed — 180°/s
Repeatability — ± 0.02 mm
SHOOTING SPEED
EVO Shooting Speed — 6.56 ft/s / 2 m/s
WEIGHTS
EVO Robot Weight — 44 lbs / 20 kg
Maximum Camera Payload — 10 lbs / 4.54 kg
Power Control Box Weight — 10.58 lbs / 4.80 kg
POWER REQUIREMENTS
Single-Phase 110V*
*Can operate on battery pack providing 110V
